WebDescription:

APRS also enables the distribution of short text messages or weather information. The Weather in the TH-D72E from his skills in particular when used outdoors and is therefore the ideal partner for example, a trekking tour.

Note also the integrated terminal controller (TNC) is the AX25 protocol compliant, allowing access to the APRS ® functions without a PC.
In addition, the Amatuerfunkverkehr can with EchoLink ® as Voice-over-IP networking problems over the Internet.

Technical data

Frequency range TX (transmitter)
144-145,995
430 to 439.995 MHz
Frequency range RX (receiver)
118-174 MHz
320-524 MHz
Transmit power
0.05 W / 0.5 W / 5W switchable
Modes
F1D / F2D / F3E
Channel spacing
uA 8.33 kHz in the aeronautical sector
Memory Channels
1000 (alpha numeric)
Features & Functions
Built-in SiRF Star III GPS logger with 5000-point function
Multi-scroll key & keyboard 16er
Built-in 1200/9600 baud TNC
APRS function
Mini-USB port
SkyCommand II System
weather-resistant construction (meets MIL-STD810 and IP54)
1750 Hz tone call
CTCSS encoder & Evaluation (42 tones)
DCS Encoder & Evaluation (104 tones)
DTMF memory (10 memories, each with 16 characters)
Dual Receive (VHFxUHF, VHFxVHF or UHFxUHF
Echolink memories
Firmware Upgradable via USB port
GPS connection (NMEA 0183)
Memory Shift function
variety of search functions
Packet Operation - AX25 KISS and Fashion
Automatic Simplex Checker
Various selectable relay racks
Separate frequencies for A and B band
Wide / Narrow Deviation
13.8V DC-in jack
Connection for external audio accessories
Kenwood double standard jack (2,5 / 3,5 mm) side of the device
Microphone Impedance 2 k ohms
Antenna connector
SMA connector
Power supply
with Battery Pack
or external with 11.73 to 15.87 V DC
Dimensions in mm (WxHxD)
58 x 121.3 x 33.2 (excluding protrusions)
Weight
370g (with battery, antenna, belt clip)

Delivery
KENWOOD TH-D72E Transceiver
Li-Ion Battery Pack PB-45L (1800 mAh)
Charger (power supply)
flexible antenna
Belt Clip
USB cable
CD-ROM (with manual and USB driver)
Instructions on paper
Weight: 0.37 kg
